Cable
RFC400
RFC400 Coaxial Cable
Custom RFC400 cable assemblies. Choose from 15 compatible connectors and any length from 1 to 1200 feet.
Specifications
About RFC400
RFC-400 is a cost-effective 0.400" 50-ohm low-loss coaxial cable serving as a value-oriented alternative to LMR-400. It delivers strong performance on runs from 50 to 200 feet and is popular for cellular repeater trunk cables, outdoor antenna feedlines, and budget-conscious infrastructure deployments.
Attenuation (dB per 100 ft)
| 100 MHz | 450 MHz | 900 MHz | 1.8 GHz | 2.4 GHz | 5.8 GHz |
|---|---|---|---|---|---|
| 1.5 | 3.3 | 4.7 | 6.8 | 7.9 | 13.0 |
Select End A Connector (15 available)
Choose the connector for the first end of your cable.
Select End B Connector
Choose the connector for the second end.
Technical Specifications
Common Applications
Frequently Asked Questions
What connectors are compatible with RFC400?
RFC400 is compatible with 15 connector types including SMA MALE, SMA FEMALE, RP-SMA MALE, RP-SMA FEMALE, N MALE, and more. All connectors can be paired in any combination.
What is the impedance of RFC400?
50 Ohm — standard for RF systems, test equipment, and antenna feedlines.
What frequency range does RFC400 support?
RFC400 supports frequencies from DC to DC – 6 GHz.
How are RFC400 cables assembled?
Every RFC400 cable assembly is hand-terminated and continuity tested at our US facility before shipping. We do not drop-ship pre-made cables — each one is built to your specifications.
What lengths are available for RFC400?
RFC400 is available from 1 ft up to 1200 ft. Use the cable builder for any custom length.
